Lindy 3 Port Mini DisplayPort MST Hub, mDP to Triple DP, with Power Supply 38428

Lindy 3 Port Mini DisplayPort MST Hub, mDP to Triple DP, with Power Supply 38428

Condition: This item is brand new and unused, supplied in the original box with instructions and power supply.

Part/Model Number: 38428

Warranty: Supplied with manufacturer's warranty.

Item details/specification.

MST hubs allow for the connection of a single Mini DP source device including computers, laptops or notebooks to 3 separate DP displays, while also providing the ability to visualise content in multiple ways.

The Lindy 3 Port Mini DP to DP MST Hub is an ideal solution for expanding or duplicating Mini DisplayPort signals across 3 DisplayPort monitors. Signals can be expanded across both displays to show large scale spreadsheets, create immersive panoramic gaming experiences or eye-catching digital signage in retail. Content can also be, independently shown on either display, great for developing a productive, multi-tasking working environment, or duplicated on both displays for use in hospitality, retail or educational scenarios.

With support up to 3840x2160@60Hz 4:4:4 8bit, content can be viewed in ultra-realistic quality, ideal for applications that require a high resolution output such as graphic design, while compatibility with a variety of graphics cards including AMD Eyefinity, ensures issue free multi-screen playback.

This active MST Hub supports DP++ and does not require the source or graphics card to support DP++ to provide dual-mode signals

Please note: This hub is not compatible with Apple products

Features

• Connects 3 DisplayPort displays to a Mini DisplayPort computer or laptop
• Expands, duplicates or displays independent mDP signals over 3 DP monitors
• Supports resolutions up to 4K 60Hz, and audio up to 7.1CH
• Compatible with various graphics cards including AMD Eyefinity, NVIDIA Surround and Intel Collage

Specification

• Interface: Mini DisplayPort (In) to DisplayPort (Out)
• Interface Standard: DP 1.2
• Supported Bandwidth: 21.6Gbps
• Maximum Resolution: 3840x2160@60Hz 4:4:4 8bit
• HDCP Support: HDCP 1.3
• Supported Audio: Up to 7.1CH

Connectors

• Input: Mini DisplayPort (Male)
• Output: 3 x DisplayPort (Female)
• Power: 5.5/2.5mm (Power supply included)

Physical Properties

• Dimensions (approx.) WxDxH: 78x60x18mm (3.07x2.36x0.71in)
• Housing Material: Metal
• Net Weight: 0.085kg (0.19lb)
• Operating Temperature: 0°C - 45°C (32°F - 113°F)
• Storage Temperature: -20°C - 70°C (-4°F - 158°F)
• Humidity: 80 - 90% RH (non-condensing)
• Power Requirements: 5VDC 3A
• Colour: Black

Miscellaneous

• Packaging Type: Carton Box
• Packaging Dimensions: 240x145x60mm (9.45x5.71x2.36in)
• Gross Weight: 0.408kg (0.9lb)
• Certified: CE, UKCA, FCC, RoHS, UL & REACH

Package Contents

• Mini DisplayPort MST Hub
• Multi-country PSU (UK, EU, US & AUS)
• Lindy Manual

Purchasing Information

• Part No.: 38428
• EAN: 4002888384285
