Siemens / Unify OpenScape Business X5R Telephone System (S30777-U776-X901-4)

Siemens / Unify OpenScape Business X5R Telephone System (S30777-U776-X901-4)

Condition: This item has been removed from a clean office environment. It is in good used condition and in full working order. It is sold as the phone system, with 2x add-on cards, and rack brackets only (as pictured). Power cables, other cables, software, instructions etc are all NOT included. What you see in the photos is what you will receive.

Part/Model Number: OpenScape Business X5R  /  S30777-U776-X901-4

Warranty: This item is sold with a 90 Day Return to Base (RTB) warranty.

Item details/specification.

Overview
OpenScape Business X1, X3, X5 or X8 are "All-In-One" HW platforms with onboard IP access and support for up to 500 subscribers with IP, digital (UP0E), ISDN (BRI), analog (a/b), cordless (DECT) devices. UC Smart application is fully embedded. Connection to public WAN is done via SIP (LAN), ISDN (BRI and PRI) or analog trunks.

UC Booster Platforms
Two UC Booster options are available for OpenScape Business X3/X5 or X8:
OpenScape Business UC Booster Card is a Plug-In module for OpenScape Busness X3,X5 and X8. It is required for the UC Suite solution up to 150 UC users
OpenScape Business UC Booster Server is required for OpenScape Business X3/X5/X8 in case of of more than 150 UC users. The UC Booster Server is based on Linux (Novell SLES) and can be operated either on a server HW directly or in vitualized environment using VMware vSphere.
By using the UC Booster options the X3R, X5R and X8 models also can be enhanced with the following functions:
OpenStage Gate View with up to two cameras, Open Directory Service, CSTA interface for connecting external applications

Software Platforms
OpenScape Business S is the server-based "All-In-One" telefony and UC platform, which supports up to 500 IP subscribers and IP (SIP) connection to the public network (WAN). It is designed for Linux (Novell SLES) operating system and can be operated either on a physical or on virtual machines with VMware vSphere. OpenScape Business S can be networked with OpenScape Business X1, X3, X5 or X8 as gateway for ISDN or anlog trunks or TDM / analog devices.

Features
OpenScape Business combines the best of the HiPath 3000 and OpenScape Office in a unified software solution architecture based on modern and innovative communication technologies. All-In-One Unified Communication solution for small and medium enterprises | Integrated voice services | Presence management (presence status) | Drag and Drop Conference | Visual voicemail | Instant Messaging (IM) | Mobility
Directory access with database connection | Fax support | Integration into business processes etc.
Multichannel Contact Center | Integration of OpenScape Web Collaboration | Multiple Sites support | Unified solution architecture Scalable and flexible HW / SW and licensing | Easy to handle migration from HiPath 3000 to OpenScape Business | System box and almost all existing devices can be reused only the motherboard and the SW has to be replaced.

Voice features
Making calls: Setting up a connection, e.g., via speed dialing or directories | Call Signaling, Calling Line ID: CLIP, CLIR, COLP und COLR. | Functions during the call: Holding, redirecting and transferring calls | Controlling availability: Call forwarding and call forwarding - no answer
Conferencing: Different types of application-controlled and phone-controlled conferences | Optimizing communication: Handling calls more efficiently and sending texts to internal subscribers | Easy Operation: Resetting activated features, Direct Inward System Access (DISA) and multilingual text output | Working in a team (groups): Multiple subscribers and phones can be reached under one station number | UCD (Uniform Call Distribution): Uniform distribution of incoming calls to a group of subscribers (UCD group). | Emergency Calls: Hotline/Hotline after timeout or an emergency service

Supported phones and devices
OpenStage phones (IP/HFA, SIP and T)
OpenStage 5, 10 T, 15,15 T, 20, 20 E, 20 G, 20 T, 40, 40 G, 40 T, 60, 60 G, 60 T, 80 G, 80 T
OpenScape Desk Phone (SIP)
OpenScape Desk Phone IP 35G and OpenScape Desk Phone IP 55G
OpenStage Key Modules
OpenStage Key Module 40, 60 and 80 for OpenStage 40 and 60
OpenStage Key Module 15 only for OpenStage 15
OpenStage Busy Lamp Field 40 only for OpenStage 40

Cordless CMI/DECT - IP/DECT telephones
OpenStage S4 professional; OpenStage SL4 professional; OpenStage M3
PC Clients (HFA, SIP)
OpenScape Personal Edition (including Video support for SIP)
SIP phones (UC Suite) / AP adapter
SIP phones with RFC 3725 support.
Mediatrix 4102S (for connecting 2 Analog phones or G.3 FAX devices)
WLAN phones OpenStage WL3
Analog and ISDN phones Analog (a/b) phones
Digital (S0) ISDN phones

Unified Communications
OpenScape Business provides two alternativ flavours of Unified Communications, depending on the needs:
UC Smart
UC Smart SW is fully embedded within the OpenScape Business SW running on the motherboard of OpenScape Business X3/X5 and X8. It comprises the Unified Communications and Collaborations features of the HiPath 3000 WebServices.
Presence incl. status based announcements | Favorites incl. Call Status | Visual VoiceMail Control | CTI incl. Ad Hoc Conferencing | Directory Access | Chat | Call Journals incl. Reminder | The UC Smart solution offers several UC clients: myPortal Smart | myPortal to go | my Portal for Mobile

Features
Including mainboard, SW on SDHC card and power supply (OCPSM), integrated Power supply
6 slots for optional system modules
Without power line
2 Gigabit LAN connections (customer LAN, service)
1 Gigabit WAN connection (Internet direct)
1 USB connection (service)

Specifications
Network Ports: 2 x 10/100/1000
Cordless Phone Standard: DECT
Capacity: ITSP channels: 60
Nominal Voltage: AC 120/230 V
Dimensions: 44 cm x 38 cm x 15.5 cm
Weight: 8 kg
